Hajmi: M3-M48
Yuzaki: ZP
d | M3 | M4 | M5 | M6 | M7 | M8 | M10 | M12 | M14 | M16 | M18 |
P | 0.5 | 0.7 | 0.8 | 1 | 1 | 1.25 | 1.5 | 1.75 | 2 | 2 | 2.5 |
/ | / | / | / | / | 1 | 1 | 1.5 | 1.5 | 1.5 | 2 | |
/ | / | / | / | / | / | 1.25 | 1.25 | / | / | 1.5 | |
da | 3 | 4 | 5 | 6 | 7 | 8 | 10 | 12 | 14 | 16 | 18 |
3.45 | 4.6 | 5.75 | 6.75 | 7.75 | 8.75 | 10.8 | 13 | 15.1 | 17.3 | 19.5 | |
dw | 4.6 | 5.9 | 6.9 | 8.9 | 9.6 | 11.6 | 15.6 | 17.4 | 20.5 | 22.5 | 24.9 |
e | 6.01 | 7.66 | 8.79 | 11.05 | 12.12 | 14.38 | 18.9 | 21.1 | 24.49 | 26.75 | 29.56 |
h | 4 | 5 | 5 | 6 | 7.5 | 8 | 10 | 12 | 14 | 16 | 18.5 |
3.7 | 4.7 | 4.7 | 5.7 | 7.14 | 7.64 | 9.64 | 11.57 | 13.3 | 15.3 | 17.66 | |
m | 2.4 | 2.9 | 3.2 | 4. | 4.7 | 5.5 | 6.5 | 8 | 9.5 | 10.5 | 13 |
mw | 1.65 | 2.2 | 2.75 | 3.3 | 3.85 | 4.4 | 5.5 | 6.6 | 7.7 | 8.8 | 9.9 |
s | 5.5 | 7 | 8 | 10 | 11 | 13 | 17 | 19 | 22 | 24 | 27 |
5.32 | 6.78 | 7.78 | 9.78 | 10.73 | 12.73 | 16.73 | 18.67 | 21.67 | 23.67 | 26.16 | |
kg | 0.5 | 1 | 1.4 | 2.4 | 3 | 5.1 | 10.6 | 17.2 | 26 | 34 | 45 |
d | M20 | M22 | M24 | M27 | M30 | M33 | M36 | M39 | M42 | M45 | M48 |
P | 2.5 | 2.5 | 3 | 3 | 3.5 | 3.5 | 4 | 4 | 4.5 | 4.55 | 5 |
2 | 2 | 2 | 2 | 2 | 3 | 3 | 3 | 3 | 3 | 3 | |
1.5 | 1.5 | / | / | / | / | / | / | / | / | / | |
da | 20 | 22 | 24 | 27 | 30 | 33 | 36 | 39 | 42 | 45 | 48 |
21.6 | 23.7 | 25.9 | 29.1 | 32.4 | 35.6 | 38.9 | 42.1 | 45.4 | 48.6 | 51.8 | |
dw | 27.7 | 29.5 | 33.2 | 38 | 42.7 | 46.6 | 51.1 | 55.9 | 60.6 | 64.7 | 69.4 |
e | 32.95 | 35.03 | 39.55 | 45.2 | 50.85 | 55.37 | 60.79 | 66.44 | 72.09 | 76.95 | 82.6 |
h | 20 | 22 | 24 | 27 | 30 | 33 | 36 | 39 | 42 | 45 | 48 |
18.7 | 20.7 | 22.7 | 25.7 | 28.7 | 31.4 | 34.4 | 37.4 | 40.4 | 43.4 | 46.4 | |
m | 14 | 15 | 15 | 17 | 19 | 22 | 25 | 27 | 29 | 32 | 36 |
mw | 11 | 12.2 | 13.2 | 14.8 | 16.5 | 18.2 | 19.8 | 21.5 | 23.1 | 24.8 | 26.5 |
s | 30 | 32 | 36 | 41 | 46 | 50 | 55 | 60 | 65 | 70 | 75 |
29.16 | 31 | 35 | 40 | 45 | 49 | 53.8 | 58.8 | 63.8 | 68.1 | 73.1 | |
kg | 65 | 75 | 100 | 162 | 212 | 317 | 415 | 499 | 628 | 771 | 998 |
Bo'shashishga qarshi usul:
* Mexanik bo'shashmasdan
* Perchin va bo'shashmasdan
* Bo'shashishga qarshi ishqalanish
* Bo'shashishga qarshi tuzilish
* Bo'shashishni oldini olish uchun yuvish usuli
Yong'oqning uchta afzalligi:
Birinchidan, tebranishga qarshi mukammal ko'rsatkich: Ip mahkamlanganda murvatning tepa ipi mahkamlash uchun nonning 30 ° takoz shaklidagi qiyaligiga mahkam kiritiladi va xanjar shaklidagi nishabga normal kuch sarflanadi. murvat bilan mos keladigan o'qi 30 ° o'rniga 60 ° burchak ostida. Shuning uchun qulf somunini tortganda hosil bo'ladigan normal kuch yumshatishga qarshi va tebranish qarshiligiga ega bo'lgan oddiy standart nondan ancha katta.
Ikkinchidan, kuchli aşınmaya qarshi qarshilik va kesishga qarshilik: yong'oq ipining pastki qismining 30 ° eğimli yuzasi, har bir tishning barcha iplariga yong'oqni qulflash kuchini teng ravishda taqsimlashi mumkin. Har bir tishning ip yuzasida siqish kuchi teng ravishda taqsimlanganligi sababli, yong'oqlar ipning aşınması va kesish deformatsiyasi muammolarini yaxshiroq hal qilishi mumkin.
Uchinchidan, yaxshi qayta ishlatish: keng foydalanish shuni ko'rsatadiki, qulfni qayta-qayta tortib va demontaj qilgandan so'ng, uning qulflash kuchi hali ham kamaymaydi va asl qulflash effekti saqlanib qolishi mumkin.
