Hajmi: -6--36
Sinf: 4.8，8.8
Yuzaki: ZP / HDG / BLSCK / DACROMET
Texnik xususiyatlari | φ3.2 | φ3.7 | φ4.3 | φ5.3 | φ6.4 | φ7.4 | φ8.4 | φ10.5 | φ13 | φ15 | φ17 | |
M | Tegishli murvat | M3 | M3.5 | M4 | M5 | M6 | M7 | M8 | M10 | M12 | M14 | M16 |
d | Eng kam | 3.2 | 3.7 | 4.3 | 5.3 | 6.4 | 7.4 | 8.4 | 10.5 | 13 | 15 | 17 |
Maksimal qiymat | 3.38 | 3.88 | 4.48 | 5.48 | 6.62 | 7.62 | 8.62 | 10.77 | 13.27 | 15.27 | 17.27 | |
dс | Maksimal qiymat | 7 | 8 | 9 | 10 | 12 | 14 | 16 | 20 | 24 | 28 | 30 |
Eng kam | 6.64 | 7.64 | 8.64 | 9.64 | 11.57 | 13.57 | 15.57 | 19.48 | 23.48 | 27.48 | 29.48 | |
h | nominal | 0.5 | 0.5 | 0.8 | 1 | 1.6 | 1.6 | 1.6 | 2 | 2.5 | 2.5 | 3 |
Maksimal qiymat | 0.55 | 0.55 | 0.9 | 1.11 | 1.8 | 1.8 | 1.8 | 2.2 | 2.7 | 2.7 | 3.3 | |
Eng kam | 0.45 | 0.45 | 0.7 | 0.9 | 1.4 | 1.4 | 1.4 | 1.8 | 2.3 | 2.3 | 2.7 | |
Og'irligi / mpcs (kg) | 0.119 | 0.155 | 0.308 | 0.443 | 1.02 | 1.39 | 1.83 | 3.57 | 6.27 | 8.62 | 11.3 | |
Texnik xususiyatlari | φ19 | φ21 | φ23 | φ25 | φ27 | φ28 | φ29 | φ31 | φ33 | φ34 | φ36 | |
M | Tegishli murvat | M18 | M20 | M22 | M24 | M26 | M27 | M28 | M30 | M32 | M33 | M35 |
d | Eng kam | 19 | 21 | 23 | 25 | 27 | 28 | 29 | 31 | 33 | 34 | 36 |
Maksimal qiymat | 19.33 | 21.33 | 23.33 | 25.33 | 27.33 | 28.33 | 29.33 | 31.39 | 33.62 | 34.62 | 36.62 | |
dс | Maksimal qiymat | 34 | 37 | 39 | 44 | 50 | 50 | 50 | 56 | 60 | 60 | 66 |
Eng kam | 33.38 | 36.38 | 38.38 | 43.38 | 49.38 | 49.38 | 49.38 | 55.26 | 58.8 | 58.8 | 64.8 | |
h | nominal | 3 | 3 | 3 | 4 | 4 | 4 | 4 | 4 | 5 | 5 | 5 |
Maksimal qiymat | 3.3 | 3.3 | 3.3 | 4.3 | 4.3 | 4.3 | 4.3 | 4.3 | 5.6 | 5.6 | 5.6 | |
Eng kam | 2.7 | 2.7 | 2.7 | 3.7 | 3.7 | 3.7 | 3.7 | 3.7 | 4.4 | 4.4 | 4.4 | |
Og'irligi / mpcs (kg) | 14.7 | 17.2 | 18.3 | 32.3 | 43.7 | 42.3 | 40.9 | 53.6 | 77.4 | 75.3 | 94.3 | |
Ta'siri:
1. Vida va mashina orasidagi aloqa maydonini oshiring.
2. Bahor yostig'i vintni tushirayotganda, mashina yuzasidagi shikastlanishni bartaraf eting. Ishlatilganda, u kamon yostig'i va tekis yostiq bo'lishi kerak. Yassi yostiq mashinaning yuzasi yonida, kamon yostig'i esa yostiq va yong'oq o'rtasida joylashgan.
Yassi yostiqlar - ishqalanishni kamaytirish, qochqinning oldini olish, izolyatsiya qilish, bo'shashmaslik yoki bosimni taqsimlash uchun ishlatiladigan har xil shakldagi ingichka bo'laklar. Ko'pgina materiallar va tuzilmalar bunday tarkibiy qismlarga ega, ular turli xil o'xshash funktsiyalarni bajarish uchun ishlatiladi. Tishli mahkamlagichlarning materiali va jarayoni bilan cheklangan, murvat va boshqa mahkamlagichlarning qo'llab-quvvatlash yuzasi katta emas. Shuning uchun, bog'langan qismning sirtini himoya qilish uchun bosim o'tkazuvchi sirtning bosim kuchini kamaytirish uchun tekis yostiqlar ishlatiladi.
